ISHIDA INS-100 - Parts List

Chapter 5 DIAGRAMS

5.3 Parts List
Grade Part Code Part Name Q’ty
2
900-2583-05 Molded Fiber
1
2
900-2582-01 Molded Fiber
1
2
900-0107-26 Power cord HY-01/HY-02 (3 X 0.75mm X 2m)
1
2
900-2833-06 INS-100
1
3
900-2568-09 Platter
1
3
900-2551-06 Platter Support
1
3
900-0016-21 Rubber-Platter Support
4
3
900-2565-08 Case
1
3
900-2566-01 Base
1
3
900-2567-05 Battery Cover
1
3
900-2576-09 Screw Washer
1
3
900-0025-15 Level Foot
4
3
900-0223-07 Level Unit
1
3
900-2829-01 Screw M2 X 4.5
8
3
900-2830-05 Screw M5 X 40
1
3
Load Cell 15Kg (C2G1-25K-S18)
1
3
Load Cell 6Kg (C2G1-10K-S18)
1
3
900-0319-01 Cushion-Battery
4
3
900-2564-04 Key Sheet
1
3
900-2562-07 Title Bar
1
3
900-2563-01 LED Name
1
3
900-1064-05 Sheet
1
3
900-2569-02 Name Plate
1
3
900-0248-00
Seal Wire ϕ1
1
3
900-0249-03 Seal Lead
1
3
900-2812-08 PWB'PS-031'Soft (D007)
1
3
900-2814-05 PWB 'PS-030' Display
2
3
900-2818-00 PWB 'PS-032' Key
1
3
900-2470-17 Harness 'S2' Key
1
3
900-2495-01 Harness 'S2' GND
1
3
900-2598-01 Harness 'S1' GND
1
3
900-2525-09 Harness 'C3' Battery
1
3
900-2483-06 Harness 'S3' Display
1
3
900-2819-03 Transformer 'LYTR-011201M-1' INS-100 220V
1
3
900-2820-08 Connector Inlet (PST-101FS PRONIC)
1
3
900-0042-00 Fuse Glass 5 X 20mm 1A
1
40 INS-100 Service Manual No. 085-6692-09
