Chapter 5 DIAGRAMS
5.4 Block Diagram
Load cell
6V Storage
battery
(6V5Ah/20HR)
Terminal
TerminalTerminal
Inle dert with fuse hol
(PST-101FS)
Earth
Earth
Terminal
Transformer
XH-2P
KK-3P
MK-10P
MK-10P
Key board (PS-032)
Main board (PS-031)
•
CPU
•
E2ROM
•
Display driver
•
Power supply circuit
•
Analog circuit
BOX-26P
BOX-26P
BOX-26P
Operator display board (PS-030) Customer display board (PS-030)
Power cable
INS-100 Service Manual No. 085-6692-09 41
