Quick Reference
• DNS1 (Primary address)
• DNS2 (Secondary address)
• Socket Port
Lan
Restore
Select whether to reset the LAN to the default set-
tings or not.
• NO
• YES
Lan Save
Select whether to save the LAN setting or not.
• NO
• YES
RS232
+CAN
When insert IT-E1207 communication board into expansion
slot, the menu displays this information.
RS232 RS232 communication interface.
Display as the following format:
baud rate_data bit_parity bit_stop bit.
• Select the baud rate from the following op-
tions: 4800, 9600, 19200, 38400, 57600,
115200
• The data bit, parity bit and stop bit are fixed:
8_None_1
CAN CAN communication interface.
Select the baud rate from the following options:
20k, 40k, 50k, 80k, 100k, 125k, 150k, 200k, 250k,
400k, 500k, 1000k.
Set the instrument address to a number from 1 to
127.
Ext
+RS485
When insert IT-E1208 communication board into expansion
slot, the menu displays this information.
Ext-
Program
Set external analog interface state. (External ana-
log interface is optional.)
Off
Turn the external analog function off.
On
Turn the external analog function on.
RS485 RS485 communication interface.
Display as the following format:
baud rate_data bit_parity bit_stop bit.
• Select the baud rate from the following op-
tions: 4800, 9600, 19200, 38400, 57600,
115200.
• The data bit, parity bit and stop bit are fixed:
8_None_1.
Copyright © Itech Electronic Co., Ltd.
11
