Technical Specification
Parameter IT6516C Ver:V1.4
Current ≤0.1%+30mA
Readback stability-30min
（％of Output +Offset）
Voltage
≤0.03%+100mV
Current ≤0.1%+30mA
Readback stability-8h
（％of Output +Offset）
Voltage
≤0.03%+100mV
Current ≤0.1%+30mA
Efficiency 91.5%(200V/15A)～93.5%(750V/4A)
Remote Sense
Compensation Voltage
5V
Command Response Time
20mS
Power Factor 0.99
Maximum input current
8
10A
Maximum input apparent
power
2000VA
Storage temperature
-10℃～70℃
Protective function
Source OVP, OCP, OPP and Load OCP, OPP, OTP,Vsense
standard Interface USB/RS232/CAN/LAN
Isolation ( output to
ground)
750V
Parallel Number ≤8
Working temperature
0～40℃
Dimension ( mm)
483mmW×105.4mmH×640.8mmD
Weight( net) 17Kg
The above specifications may be subject to change without prior notice.
1. Internal absorption current and internal absorption power mean the
absorption current and power of the standard power dissipater inside the power
supply.
2. Resistance programming accuracy differs based on different output current.
For example, 10A Transient 1.0Ω, accuracy: (1.0Ω * 0.25%) +(375mΩ*A /10A)
= 40mΩ.1.0Ω, accuracy: (1.0Ω * 0.25%) +(375mΩ*A /10A) = 40mΩ.
3. Set value accuracy means the set accuracy realized through the panel button
or communication instructions. When external analog is used for programming,
the programming accuracy is 2%FS.
Copyright © Itech Electronic Co., Ltd.
