Technical Specification
5. Up time and down time mean the time of establishment from one value to
another value under ON status when the internal standard power dissipater is
enabled.
6. Use 12V/120AH battery for test.
7. When used in parallel, to balance power of each phase, distribute the
instrument to three phases. But must ensure that single machine input voltage
meets Specification requirements.
8. It means the maximum phase current value under minimum work input
voltage.
5.1.4 IT6513C
Parameter IT6513C Ver:V1.6
Output Rating ( 0 ℃-40 ℃)
Output Voltage
0~200V
Output Current
0~60A
Internal Sink
Current
1
0~25A
Output Power
0~1800W
Internal Sink Power
1
0~150W
Output Resistance
Range
0~22.222Ω
Accuracy
2
0.25%+100mΩ
Resolution 1mΩ
Line regulation
±(%of Output+Offset)
Voltage
≤0.01%+20mV
Current ≤0.01%+30mA
Load regulation
±(%of Output+Offset)
Voltage
≤0.01%+50mV
Current ≤0.05%+60mA
Setup Resolution
Voltage
10mV
Current 10mA
Power 0.1W
Read Back Resolution
Voltage
10mV
Current 10mA
Power 0.1W
Setup Accuracy
(within 12 months,25℃
±5℃)
±(%of Output+Offset)
Voltage
≤0.05%+100mV
Current ≤0.2%+60mA
Power ≤1%+30W
Read Back Accuracy Voltage
≤0.05%+100mV
