Function and Features
E-12 Voltage Curve with Intelligent Generator Control
The behavior of the electric system when intelligent generator controls are used
is simulated. The behavior goes from DC to voltage changes within max. 300
ms.
3.21 DC Internal Resistance Measure
In addition to various test functions of original power supply, this Series of
power supply provides measure function for internal resistance at charging and
discharging the battery, which needs no various detection devices.
To measure the DUT internal resistance, turn on the DC internal resistance
measure function in the menu and set the DUT capacity. During measure, the
Meter interface will display the real-time DC internal resistance of the DUT.
DCR DC internal resistance measure
Battery Capacity =
0AH
Input battery capacity
Off/On Turn off/on DC internal
resistance measure function
Copyright © Itech Electronic Co., Ltd.
72
