Function and Features

On: the current load function is on. The user can select On or Off to turn on

or off the load function through Up/Down key. When the load is on, you need

to select internal load or external load. The instrument defaults to internal

load.

Internal: the current load is internal load. The user can select Internal (-

internal load) or External (external load) through Up/Down key.

Set load input

When using load function, the user can set load current, power and slope as

well as OCP, OPP, etc.

In internal load mode, the value of load power is defaulted to rated value, and

the value of current is defaulted to a small value. In external load mode, the

values of load power and current are defaulted to zero.

When the number of the power dissipater for external load changes, the load

limit value needs to be changes manually.

Set the load input current and input power in Setup menu. Details about load

input current/power are as shown below.

1. Press [Shift]+ [V-set](Setup) to enter the Menu operation. The interface

displays information as follows:

2. Select Load to set parameters related to the load.

LOAD

P-set I-set Slope OCP

• Select P-set to set the input power value.

• Select I-set to set input current value.

3. Press the Number key or use Knob to directly set the power or current value.

3.9.9 Setting Filter

This option sets the display filter frequency of the power supply. The filter

function of this series of power supply is averaging calculation. The average

values of different frequencies are different, as shown below: Low: 2^16; Mid:

2^14; High: 2^8.

1. Press composite keys [Shift]+[P-set](Menu) enter to system menu.

2. Select CONFIG, press [Enter] to confirm.

3. Select Filter with Left/Right key and press [Enter] to confirm.

4. Select Low, Mid or Fast with Left/Right key and press [Enter] to confirm.
