3.10 Setup Menu
In the configuration menu, the user can configure all parameters related to the
power supply and the load as well as resistance setting.
Configuration parameters of the power supply are as follows:
• Voltage/current/power slope
• OVP/OCP/OPP
• Maximum and minimum limits of voltage/current/power
Configuration parameters of the load are as follows:
• Current and power
• Current and power slope
• OCP/OPP
• Maximum and minimum limits of current/power
Setup
Source
Configure menu
Slope Set the source slope
V-Rise: voltage rise slope
V-Fall: voltage fall slope
I-Rise: current rise slope
I-Fall: current fall slope
P-Rise: power rise slope
P-Fall: power fall slope
OVP Over voltage protection of source
On(Def) Enable over voltage protection function
V: OVP value
Delay: delay time of protection
Off Disable over voltage protection function
OCP Over current protection of source
On(Def) Enable over current protection function
I: OCP value
Delay: delay time of protection
Off Disable over current protection function
OPP Over power protection of source
On（Def） Enable over power protection function
P: OPP value
