Function and Features

Off Turn on/off this

function

E-09 LV124 E-09 Reset behavior test

waveform

Ubmin Holding voltage

Off Turn on/off this

function

E-11 LV124 E-11 Start pulses

Cold-Start Cold start

Normal: normal pulse

Severe: severe pulse

Warm-Start Warm start

Off Turn on/off this

function

E-12 LV124 E-12 Voltage curve with

intelligent generator

control

ΔU Voltage drop between

DUT and battery

terminals

Off Turn on/off this

function

3.20.1 Automotive Starting Waveform

IT6500C models have built in DIN40839 waveform. This test verifies the

behavior of a DUT during and after cranking. This waveform can reproduce the

voltage curve for automotive power network confirms to DIN 40839 standard,

thus facilitating quick call by customers.

For automotive startup voltage waveform, the startup voltage can also be set

based on customers’ requirements. In this way, the user can create waveform

between 8V to 32V.
