Remote Control
• NONE 8 data bits have no parity
Native machine address: (0 ~31, factory default is 0)
Start Bit 8 Data Bits Parity=None Stop Bit
4.2 USB Interface
Use a cable with two USB ports to connect power supply and PC. You can
program through USB interface to achieve all functions of power supply.
The functions of USB488 interface are as follows:
• Interface is 488.2 USB488 interface
• Receive the following request: REN_CONTROL, GO_TO_LOCAL, and
LOCAL_LOCKOUT
• When the interface receives MsgID = TRIGGER USBTMC command, it will
transmit the TRIGGER command to the function layer
The functions of power supply’s USB488 are as follows:
• receive all SCPI commands
• device is SR1 enabled
• device is RL1 enabled
• device is DT1 enabled
4.3 GPIB Interface (Only for IT6500(G) Series)
Use a IEEE488 bus to connect GPIB interfaces of power supply and PC. Please
ensure that the screws have been screwed down in order to have a full
connection. Then press [Shift] +[P-set] (Menu) to enter the system menu to set
the address. The address range of power supply is 1-30. After you set the
address, please press [Enter] button to confirm. GPIB address is saved in
nonvolatile memory.
Copyright © Itech Electronic Co., Ltd.
85
