Technical Specification
5. Up time and down time mean the time of establishment from one value to
another value under ON status when the internal standard power dissipater is
enabled.
6. Use 12V/120AH battery for test.
7. When used in parallel, to balance power of each phase, distribute the
instrument to three phases. But must ensure that single machine input voltage
meets Specification requirements.
8. It means the maximum phase current value under minimum work input
voltage.
5.1.7 IT6514C
Parameter IT6514C Ver:V1.6
Output Rating ( 0 ℃-40
℃)
Output Voltage
0~360V
Output Current
0~30A
Internal Sink
Current
1
0~12.5A
Output Power
0~1800W
Internal Sink
Power
1
0~150W
Output Resistance
Range
0~72Ω
Accuracy
2
0.25%+135mΩ*A
Resolution 1mΩ
Line regulation
±(%of Output+Offset)
Voltage
≤0.01%+40mV
Current ≤0.01%+15mA
Load regulation
±(%of Output+Offset)
Voltage
≤0.01%+135mV
Current ≤0.05%+30mA
Setup Resolution
Voltage
10mV
Current 10mA
Power 0.1W
Read Back Resolution
Voltage
10mV
Current 10mA
Power 0.1W
Setup Accuracy
3
(within 12 months,25℃
±5℃)
±(%of Output+Offset)
Voltage
≤0.05%+135mV
Current ≤0.2%+30mA
Power 1%+30W
Copyright © Itech Electronic Co., Ltd.
109
