Technical Specifications
Copyright © ITECH Electronic Co., Ltd. 65
protection
Overcurrent
protection
55A 550A
Overvoltage
protection
130V
Overtemperatur
e protection
85
Specification
Short circuit
Current (CC)
55A 550A
Voltage (CV)
0V 0V
Resistance
(CR)
2mΩ 2mΩ
Input terminal
impedance
300KΩ
Dimension
12U
Model IT8830B
Rated value
( 0-40 °C)
Input voltage
0~500V
Input current
0~20A 0~200A
Input power
10KW
Min. operating
voltage
0.3V/20A 3V/200A
Constant
voltage
mode
Range
0.1~50V 0.1~500V
Resolution
1mV 10mV
Accuracy
±(0.025%+0.05%FS) ±(0.05%+0.05%FS)
Constant
current
mode
Range
0~20A 0~200A
Resolution
1mA 10mA
Accuracy
±(0.05%+0.05%FS) ±(0.05%+0.05%FS)
Constant
resistance
mode *1
Range
0.02Ω~10Ω 10Ω~7.5KΩ
Resolution
16bit
Accuracy
0.01%+0.08S *2 0.01%+0.0008S
Constant
power
Mode *3
Range
10KW
Resolution
1W
Accuracy
0.2%+0.2%FS
Measuring range
Read-back
voltage
Range
0~50V 0~500V
Resolution
1mV 10 mV
Accuracy
±(0.025%+0.025%FS) ±(0.025%+0.025%FS)
Read-back
current
Range
0~20A 0~200A
Resolution
1mA 10mA
Accuracy
±(0.05%+0.05%FS)
Read-back
power
Range
10KW
Resolution
1W
