Technical Specifications
Copyright © ITECH Electronic Co., Ltd. 75
terminal
impedance
Dimension
37U 37U
Model IT8836B IT8836H
Rated value
( 0-40 °C)
Input voltage
0~500V 0~800V
Input current
0~80A 0~800A 0~40A 0~400A
Input power
40KW 40KW
Min. operating
voltage
0.3V/80A 3V/800A 0.3V/40A 3 V/400A
Constant
voltage
mode
Range
0.1~50V 0.1~500V 0.1~80V 0.1~800V
Resolution
1mV 10mV 1mV 10mV
Accuracy
±(0.025%+0.05%FS) ±(0.05%+0.05%FS)
Constant
current
mode
Range
0~80A 0~800A 0~40A 0~400A
Resolution
1mA 10mA 1mA 10mA
Accuracy
±(0.1%+0.1%FS) ±(0.1%+0.1%FS) ±(0.05%+0.1%FS) ±(0.05%+0.1%FS)
Constant
resistance
mode *1
Range
0.01Ω~10Ω 10Ω~7.5KΩ 0.01Ω~10Ω 10Ω~7.5KΩ
Resolution
16bit 16bit
Accuracy
0.01%+0.08S *2
0.01%+0.0008S
0.01%+0.08S *2
0.01%+0.0008S
Constant
power
Mode *3
Range
40KW 40KW
Resolution
1W 1W
Accuracy
0.2%+0.2%FS 0.2%+0.2%FS
Measuring range
Read-back
voltage
Range
0~50V 0~500V 0~80V 0~800V
Resolution
1 mV 10 mV 1 mV 10 mV
Accuracy
±(0.025%+0.025%FS)
Read-back
current
Range
0~80A 0~800A 0~40A 0~400A
Resolution
1mA 10mA 1mA 10mA
Accuracy
±(0.05%+0.1%FS) ±(0.05%+0.05%FS)
Read-back
power
Range
40KW 40KW
Resolution
1W 1W
Accuracy
±(0.2%+0.2%FS) ±(0.2%+0.2%FS)
Protection range
Overpower
protection
≒40.1KW ≒40.1KW
Overcurrent
protection
≒88A ≒880A ≒44A ≒440A
Overvoltage
protection
≒530V ≒850V
Overtemper
ature
protection
≒85℃ ≒85℃
Specification
Short circuit
Current (CC)
≒88/80A ≒880/800A ≒44/40A ≒440/400A
