6.3 Process LED (Red )
Blinking Normal Mode
Off Powered Down
Table 5: Process LED Behaviour
6.4 GSM LED (Green )
Behaviour
Significance
Off Module/Device Off
64ms on/ 800ms off Not synchronised with network
Registered to the network
Table 6: GSM LED Behaviour
7 Configuration
7.1 System requirements
Operating system version: 32-bit and 64-bit.
Operating system: Windows 7 and later.
Java: JDK and JRE 8.0 and above.
USB to Serial converter
DB9 Connector with open ended wires
7.2 Setup Java Environment
7.2.1 Installation of JDK
Download and follow below procedure for installing jdk 1.8. Download the appropriate jdk
(32bit/64bit) based on the system which it is intended to use.
http://www.oracle.com/technetwork/java/javase/downloads/jdk8-downloads-2133151.html
Select and open the downloaded file.
Pop up message will come by requesting Yes or No. select Yes.
Below mentioned window will appear.
