Figure 12:Edit environmental variables
7.3 Configuration Setup
To configure the device below is the hardware setup which should be rigged up.
7.3.1 Preparation of DB9 connector.
Below is the table of wire colour with respect to PIN number of DB9 female connector.
Sl No Wire Colour DB9 PIN Number
1 Orange PIN2
2 White PIN3
3 Black PIN5
Table 7: DB9 pinout
Solder the wire to different PINs of DB9 Connector as per above table. Refer the below figure for the
reference.
Figure 13:DB9 connector
