will control and monitor other devices/status on remote asset. TS101-Basic also has a program port
for device status log output and configuration of the device.
3.1 Contents of the package
Usually the TS101-Basic device is supplied to the customer in a cardboard box will have below
contents.
 TS101-Basic device.
 Vehicle Harness Cable with 8 pin connector.
 Cable ties for installation.
 Warranty card.
3.2 Basic Characteristics
3.2.1 GSM/GPRS
 Quad - Band 850/ 900/ 1800/ 1900MHz
 GPRS: Class 12, Coding Scheme CS1,2,3,4, USSD
 Text and PDU Mode
3.2.2 GNSS Module
 99 search channels for acquisition and 33 simultaneous tracking channels.
 SBAS: WAAS, EGNOS, MSAS, GAGAN
 Tracking Sensitivity of -167dBm.
 Inbuilt patch antenna.
 Horizontal position accuracy: Autonomous:<2.5m CEP
3.2.3 Hardware features
 MT2503 Chip set (ARM7).
 Solid State Flash 4M, 100K Erase and Program Cycle, 10 Year data retention.
 Internal backup battery.
 Supports SIM card: 1.8V and 3V Micro SIM.
 Embedded SIM [Optional].
 GNSS back up battery for quicker fix.
3.2.4 Interface features
 Wide DC Input Voltage Range [9V – 32V].
 1 dedicated ignition input.
 1 Digital Input.
 1 Digital Output [Open drain].
 1 Analog Input.
 LEDs indicating device status.
3.3 Firmware Features
 Detect Harsh Breaking, Harsh Acceleration.
 Firmware upgrade over the air Available.
 Configuration over the air (Both SMS and GPRS).
 Case open detection.
 Data acquisition – Heading & time based.
