Erreur ! Utilisez l'onglet Accueil pour appliquer Heading 1 au texte que vous souhaitez faire apparaître ici.
Terminal
Phase
Function
Terminal
Phase
Function
1
1
I1 - Phase 1 in
7
3
I3 - Phase 3 in
2
No connection
8
No connection
3
1
I1 - Phase 1 out
9
3
I3 - Phase 3 out
4
2
I2 - Phase 2 in
10/11
No connection
5
No connection
12
No connection
6
2
I2 - Phase 2 out
Typical wiring illustrated below:
