Specification Specification value
Accuracy Class 1 and ±0.5% at room temperature
Meter type Temperature compensated (TC) or non-temperature compensated (NTC)
Hub center-to-center 6 inches (152.4 mm)
Hub size options
■
10LT
■
20LT
■
30LT
■
1A/Sprague standard
■
1-1/4", 1" Pittsburgh
■
ISO G 1-1/4"
Meter MAOP 5 PSIG (35 kPa)
Valve Actuated swing valve, maximum 0.035 CFH (1 L/H) leakage rate
LCD displayed units CCF (100 x cubic foot) or cubic meter
LCD resolution 00000.001 CCF (0.1 CF) or 00000.001 m
3
Case Aluminum case with ASA 49 gray powder coat finish
Weight 4.5 lbs (2.0 kg)
Gas type Natural gas Type H, E, L (per EN 437)
Reference gases G20, G21, G23, G25, G26, G27
Component materials
■
UMU (ultrasonic measuring unit): polybutylene terephthalate (PBT) and polycar-
bonate (PC)
■
Valve plastics: PBT
■
Inlet and outlet tubes: polyoxymenthylene (POM)
Intrinsically safe For use in Class I, Division 1, Group D hazardous locations. Temp Code T1 -40°C
≤ Ta ≤ +70°C
IECEx UL 18.0144X Ex ia IIA T1 Ga
Regulatory FCC: Part 15.247, Part 15.249 (programming)
FCC ID: EWQINTELISG
Innovation, Science, and Economic Development Canada (ISED): RSS-247 and
RSS-210 (programming)
IC ID: 864D-INTELISG
Measurement Canada: Pending
Table 1Intelis Gas Meter specifications (continued)
11 December 2019 TDC-1782-005 13
Intelis Gas Meter Installation Guide 2 Intelis Gas Meter
