4
LCD Operation
This section provides information about the Intelis Gas Meter LCD.
Intelis Gas Meter LCD
This section describes the Intelis Gas Meter LCD menus that are displayed in a pre-defined
order (1-8).
Note: The Intelis Gas Meter ships in a sealed (locked) state.
Additionally, there are two screens that display in response to an overflow or test condition.
Note: The two additional menu pages provide overflow condition information and an inter-
face to perform an LCD test.
The LCD test is initiated by a long press. These additional menu pages are not a part of the nor-
mal sequence. The LCD normal mode is off. A button press will activate the LCD. Each menu
page is active for 6 seconds before the LCD advances to the next menu page. When the last
menu page is reached, the process loops to the first menu page until the configured timeout is
reached.
Note: A button press will also advance the LCD to the next menu page.
11 December 2019 TDC-1782-005 20
