A B C D E F G
8.4 inches 6.4 inches 6.0 inches 5.4 inches 3.1 inches 9.1 inches 1.9 inches
214.4 mm 161.9 mm 152.4 mm 138.3 mm 78.6 mm 230.6 mm 48.8 mm
Table 2Intelis Gas Meter dimensions
Note: B dimension can vary with different hubs options. (20LT is shown).
11 December 2019 TDC-1782-005 15
Intelis Gas Meter Installation Guide 2 Intelis Gas Meter
