Task Action See...
5
Connect the Mobile Collection computer to the
MC3Lite radio.
To connect power to the Mobile
Collection dock on page 33
6 Connect power to the Mobile Collection junction box.
To connect power to the radio on
page 34
7 Connect data cables to the Mobile Collection system.
Connecting the GPS and Data
Cables on page 36
Mobile Collector Sled
For portable mounting, the Mobile Collector sled is used to securely fasten the Mobile
Collection computer in the vehicle. It is placed on the passenger seat and secured with a
seat belt and pretensioner.
Note: Watch the Mobile Collector safety video and read the Mobile Collector Sled and
Pretensioner Installation Guide (TDC-0708-xxx) to learn how to correctly install the sled in
your vehicle. These materials are located in a plastic sleeve on the underside of the sled.
The Mobile Collection vehicle dock attaches to the sled and serves as a locking base and
provides power and communications to the computer. There are different docks available
depending on computer.
A power junction box ships in the Mobile Collection kit. Attach this power junction box to the
sled. When attached, the junction box on the sled should face the passenger side door of
the vehicle.
Install the sled on the passenger seat before mounting the MC3Lite radio. You must install
the sled with the seat belt pretensioner. For more information within this document, see Seat
Belt Pretensioner on page 13.
The sled components are shown on the sled below.
Installing MC3Lite Components
MC3Lite Vehicle Preparation and Hardware Installation Guide TDC-1548-002 12
Proprietary and Confidential
