ID Item Description
1 Mobile Collection sled
Attaches to the vehicle passenger seat with the seat belt
and pretensioner system.
2 Mobile Collection vehicle dock
Attaches to the Mobile Collection computer and provides a
secure base for the computer while in the vehicle.
3 Junction box
Provides power to the various Mobile Collection
components. Attach the junction box prior to first use.
Seat Belt Pretensioner
The seat belt pretensioner makes the three-point safety harness in your vehicle function
similarly to a lap seat belt. By using the pretensioner mechanism to cinch the mounting
hardware very firmly into the junction of the seat back and the seat pad, the pretensioner
restricts potentially hazardous equipment movement in the event of an impact.
Installing MC3Lite Components
MC3Lite Vehicle Preparation and Hardware Installation Guide TDC-1548-002 13
