FZ-M1 Tablet Dock
The following table shows the key parts for each computer dock.
ID Description
1 Barrel lock (on back)
2 Latch handle
3 Latch hook
4 Docking connector and ground pins
To attach the tablet to the vehicle dock
Refer to the instructions that come with your computer and dock.
1.
Ensure the dock is unlatched by pulling the latch handle down.
Installing MC3Lite Components
MC3Lite Vehicle Preparation and Hardware Installation Guide TDC-1548-002 18
Proprietary and Confidential
