Electromagnetic Compatibility
Caution: Use only approved accessories with this equipment. All cables must be
high quality, shielded, correctly terminated, and normally restricted to 2 meters in
length. Unapproved modifications or operation beyond or in conflict with these use
instructions may void the authority's authorization to operate the equipment.
SUPPORTED VEHICLE INFORMATION
Itron's Mobile Collection systems are designed for use in land mobile vehicles such as cars,
trucks, and vans conforming to U.S. Department of Transportation standards. Use of any
Mobile Collection system in an aircraft is not supported by Itron nor certified for transmitting
by the Federal Aviation Administration and/or Transport Canada. Consult your local Aviation
Authority for additional guidance.
Warning: Do not visually monitor or physically adjust the Mobile Collection system
while driving. While driving, rely on the beeps produced when meter data is collected
to indicate proper system operation. Visually monitoring or adjusting the Mobile
Collection system while driving will divert your attention from your safe driving
responsibilities. Attention to driving is your primary responsibility, along with following
all the applicable driving regulations.
Mobile Collector 3 Lite Antenna Specifications
This section provides the specifications for the Mobile Collector 3 Lite antennas.
Caution: The Mobile Collection system is designed to operate with the antennas
listed here. Antennas not listed here are strictly prohibited for use with the Mobile
Collection system. The required antenna impedance is 50 ohms.
Specification 915 MHz Mobile Antenna Mobile Antenna Mount with GPS
Antenna
Itron part number MSE-0122-002 CBA-0334-001 or CBA-0335-001
Frequency range 908-958 MHz 1574-1576 MHz
Maximum gain 5 dBi 3 dBi
Polarization Vertical Omnidirectional Right-Hand Circular
Impedance 50 ohms 50 ohms
Termination 1-1/8"-18 thread mount
SMA male (GPS)
TNC male (Mobile)
Overall dimensions 26.5” L x 1.43” D 2.25” x 4.25” x 1.25”
Before You Begin
MC3Lite Vehicle Preparation and Hardware Installation Guide TDC-1548-002 3
Proprietary and Confidential
