Dimensions and Weights
Section 6
HVM1202, HVM1203, HVM3403, 3405
All dimensions in inches! Drawings are not to scale!
Dimensions are nominal
Type
Weight [lbs]
Basic Master / Single
2, 3 HP
1 Ph
8.8 9.7
3, 5 HP
3 Ph
a … minimum center-distance between HYDROVARs 12"
b … header space for maintenance 12"
7.4
7.9
8.9
3.353.35
6.7
7.9
8.2
