ITT Hydrovar User Manual

63
Programming
Config. Explanation of status Action if status=YES
Power HYDROVAR is connected to power supply
Relay 1: X5/ 1-3 closed
Relay 2: X5/ 4-6 closed
Running Motor is running
Relay 1: X5/ 1-3 closed
Relay 2: X5/ 4-6 closed
Errors An error is indicated on the HYDROVAR Relay 1: X5/ 1-2 closed
(incl. power failure) Relay 2: X5/ 4-5 closed
Warnings A warning is indicated on the HYDROVAR
Relay 1: X5/ 1-2 closed
Relay 2: X5/ 4-5 closed
StandBy
Pump is manually turned off or E-stop activated, Relay 1: X5/ 1-3 closed
no error/warning is indicated and HYDROVAR doesn’t run Relay 2: X5/ 4-6 closed
Errorreset
If Parameter ERRORRESET [0615] is activated and a Relay 1: X5/ 1-3 closed
Warning occurs 5 times -> Error -> Relay 2: X5/ 4-6 closed
Error of
A failure is indicated at least on one Basic drive
Relay 1: X5/ 1-2 closed
Basics Relay 2: X5/ 4-5 closed
Warnings A warning is indicated on the Master or Relay 1: X5/ 1-2 closed
+ Basics at least one Basic drive Relay 2: X5/ 4-5 closed
0800
0800 SUBMENU
REQUIRED VALUES
0805
0805 C.REQ.VAL 1
Configuration required value 1
digital
Possible settings: - digital - analog U 0-10V
- analog I 0-20mA - analog I 4-20mA
Digital
The internal required value 1 is used.
Setting in the main menu in Parameter 02 or parameter [0820].
analog U=0 – 10V
The required value 1 is determined by the value of a voltage signal
(0 – 10V) connected to terminals X3/13- X3/14 (GND).
The required value 1 is determined by the value of a current signal
analog I=0 – 20mA (4 – 20mA or 0 – 20mA) connected to terminals X3/18- X3/17
(GND).
Notice: If the incoming current signal drops below 4mA (4-20mA
analog I=4 – 20mA setting), a warning message is shown on the display. If the failure is
still active after 20 seconds, an error message will be shown.
The changeover between the 1st and the 2nd required value can be done either internally or externally via
the digital inputs. With the following parameters the source of the required values and the change over
can be configured.
