44
G
Programming
This value displays the output frequency generated by the HYDROVAR.
47
47 VER. INVERTER
Software version of the selected drive
01
This parameter displays the software version of the BASIC drive (located on the main board).
Possible indications:
00 All power sizes (2-15 HP) prior production 05/2008
01 Sizes HV 2 - 5 HP - related to control board software V01.3
02 Sizes HV7.5 - 15 - related to control board software V01.3
60 60 SUBMENU SETTINGS
Note
Carefully read these instructions before changing the remaining parameters.
Improper settings can cause the drive to malfunction.
These parameters can be changed during operation. Therefore they should be changed only by trained
and qualified technicians. It is recommended to stop the HYDROVAR by pressing ▼ in the main menu
before changing parameters in submenues.
61
61 PASSWORD
enter password (0066 = Default) by pressing ▲ or ▼
0000
NOTICE! If the submenu is opened with the correct password it will remain open for
a period of 10 minutes without entering the password again to access the secondary
menu.
61 PASSWORD
Confirm by pressing and the first window of the sub menu is shown
0066
62
62 JOG 0.0Hz
Both current output frequency and actual value are shown.
X.XX PSI
• By pressing ▲ or ▼ in this menu, the drive switches from control via external input (transducer) to
manual frequency control.
• Use the ▲ and ▼ buttons to change output frequency and pump speed to achieve the desired pressure
and flow.
• If this value becomes 0.00 Hz the HYDROVAR stops.
• Exit this menu by pressing or , and the HYDROVAR returns to the previously selected mode.
