Programming
0910
0910 LEVEL 1
Offset active between 0 and LEVEL 1
0
Possible settings: 0 – OFFSET RANGE
0912
0912 OFFSET X1
Offset signal value
0
Possible settings: 0 – LEVEL 1
Designation of the x – coordinate as absolute value.
0913
0913 OFFSET Y1
Desired value
0.00 PSI
Possible settings: 0 – standardization of the sensor
Desired value; designation of the y – coordinate as absolute value.
0915
0915 LEVEL 2
Offset active between LEVEL 2 and OFFSET RANGE
100
Possible settings: LEVEL 1 – OFFSET RANGE
0917
0917 OFFSET X2
Offset signal value
100
Possible settings: LEVEL 2 – OFFSET RANGE
Designation of the x – coordinate as absolute value.
0918
0918 OFFSET Y2
Desired value
0.00 PSI
Possible settings: 0 – standardization of the sensor
Desired value; designation of the y – coordinate as absolute value.
