mP4G/mP4GL Motherboard
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
User’s Manual
7•2
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
mP4G/mP4G-U Motherboard Specifications
Processor:
Single processor for Intel 478 Pentium 4
Frontside Bus - 533Mhz
System Bus - 133MHz
Supports Pentium 4 Celeron, Willamette & Northwood processors
Auto detects CPU type, external clock and multiplier
CPU external clock adjustment at 1MHz/step in BIOS CMOS Setup Utility
CPU Power:
Follows VRM 9.0 specification
VRD design
Two phases
Memory:
PC1600/PC2100 DDR SDRAM
Unbuffered DDR SDRAM
2 DIMMs up to 2GB
Chip Set:
North Bridge: Intel 845G
South Bridge: ICH4
Winbond Super I/O: W83637HF
Graphics:
Onboard AGP display with VGA port
One AGP 4X slot
PCI:
Three 32-bit PCI/33MHz slots
PCI 2.1/2.2 Compliant
LAN:
RealTek 8100 LAN on board
RJ-45 connector
Reader Device Support:
Memory Stick Reader connector
Secure Digital Reader connector
Smart Card Reader connector
USB 2.0
Three USB 2.0 external ports on the rear panel
Two USB 2.0 external ports by onboard pin header for front panel
One USB 2.0 onboard internal port
Audio:
AC’97 5.1- channel Codec
Rear panel Line Out/MIC jacks (mP4G-U) or Line Out/Line In/MIC jacks (mP4G)
Supports Mic/Line Out connectors for Smart Panel
One 4-pin CD-ROM Audio-In header
One 4-pin Audio-In AUX header
