5-44 4181384 First Edition
HYDROSTATIC POWER TRAIN
5
Figure 5-86
23. Install four screws (39) in the valve housing (40).
Tighten screw using an alternating pattern to 55—
59 lb-ft (75—80 N·m).
TN1294
39
40
39
