Jacobsen HR800 Service Manual

11 SPECIFICATIONS
en-113
11.4 VIBRATION ______________________________________________________________
The machine was tested for hand and arm vibration levels. The operator was in the normal position to drive the vehicle,
with two hands on the steering mechanism. The engine was in operation and the cutting device was in rotation. No
drive was engaged.
The Machinery Safety Directive 2006/42/EC
By compliance to:
The Lawnmower Standard BS EN ISO5395-3:2013
Referenced to Hand/Arm: BS EN ISO20643:2008
Information Supplied for Physical Agents Directive 2002/44/EC
By reference to:
Hand/Arm Standards: BS EN ISO 5349-1 (2001)
BS EN ISO 5349-2 (2002)
Whole-body vibration measurement was carried out with the machine traveling in a straight line at a speed close to 6
km/h on a flat horizontal level surface. The height of cut was set at the lowest position and the cutting means engaged.
Each reading shall be obtained from a signal time suitable
The Machinery Safety Directive 2006/42/EC
By compliance to:
Whole Body EN1032:2003
Information Supplied for Physical Agents Directive 2002/44/EC
By reference to:
Whole Body Standards BS EN ISO 2631-1 (1997)
HR800
Hand / Arm Acceleration
Level
70543 with ROPS
HR800
Hand / Arm Acceleration
Level
70543 with Cab
Maximum Accelerations m/s² Maximum Accelerations m/s²
0.552 ± 1.4 0.343 ± 1.4
HR800
Whole Body Acceleration
Level
70543 with ROPS
HR800
Whole Body Acceleration
Level
70543 with Cab
Maximum.Acceleration m/s² Maximum Acceleration m/s²
0.247 ± 0.1 0.257 ± 0.1
