7 MAINTENANCE AND LUBRICATION
en-97
7.25 LUBRICATION OF CUTTING UNIT ____________________________________________
Wing Pivot Arm (A)
Front Pivot Arm (B)
Caster Wheel Mounting Pivot (C)
A
A
B
C
C
