MAINTENANCE AND LUBRICATION 7
en-86
7.11 AIR CLEANER ____________________________________________________________
Check the service indicator (1) each day. If the red band become visible in
the window (2), replace the filter elements.
Do not remove the elements to inspect or clean. Removal of the filter that
is not necessary increases the risk of dust and other particles to enter the
engine.
When service is needed, first clean the outside of the filter housing (4),
then remove the primary (5) and secondary (6) filter elements carefully.
Clean the inside of the filter housing. Make sure dust and other particles
do not get into the engine inlet hose.
Inspect the new elements. Do not use a damaged element and never use
an incorrect element.
Assemble the secondary (6) and primary (5) filter elements. Make sure
the elements seat correctly. Press the button (3) to set the service indicator.
Assemble the cap (7) to the filter housing (4). Make sure the cap seals around the filter housing. The dust valve (8) on
the cap must be at the bottom of the filter. Fasten the cap with the two clips.
Check the air filter hoses for wear or damage. Make sure the hose clamps are tight and hold the hoses in position.
