4 CONTROLS
en-49
4.3 TRACTION PEDAL ________________________________________________________
The traction pedal is found on the right side of the footplate.
• Carefully press the top (A) of the foot pedal to reach the forward speed that
you need.
• To stop - Carefully return the foot pedal to the Neutral position.
• To move in the reverse direction press the bottom (B) of the foot pedal
4.4 STEERING TILT CONTROL _________________________________________________
With the operators seat is in the correct position to operate the traction pedal. While you
hold the steering wheel, press the small foot pedal (A) at the base of the steering
column.
Tilt the column backward or forward to the correct position. Release the small foot pedal
to lock the steering column in position.
A
B
A
