Jacobsen HR800 - Maintenance and Lubrication; 7.1 Maintenance and Lubrication Charts

7 MAINTENANCE AND LUBRICATION
en-73
7Maintenance and Lubrication
7.1 MAINTENANCE AND LUBRICATION CHARTS __________________________________
Machine Service Interval Chart
Interval Item Section
First 50 hours
 Change the Hydraulic Filter Elements
8.7
Each day
10 hours
 Check Safety Interlock System
 Check the Hydraulic Fluid Level
 Check tire Pressure
 Check Engine Bay for Dirt
6.2
8.6
8.17
8.22
Each week
Every 50 hours
 Check for Loose Components
 Check Cutter Blades
 Check for Hydraulic Leaks
8.12
8.20
3.1.8
End of season
Every 1000 hours
 Check Battery Condition
 Change the Hydraulic Oil and Filters
8.12
8.6
Lubricate these fittings every week
A = All Lift Arm Pivots.
B = All Cutter Deck Caster Wheel Pivots.
Fluid Requirements
Quantity Type
Engine Oil (with filter) 11.2 liters 2.46 Imp gals 2.96 US gals 10-30W (see specification below)
Hydraulic Oil (with filter) 75.7 liters 16.7 Imp gals 20 US gals Total Equivis ZS46 (ISO VG 46)
Radiator Coolant 7.6 liters 1.67 Imp gals 2.0 US gals 50% Anti-Freeze
Fuel 109.8 liters 24 Imp gals 29 US gals #2-D (ASTM D975) Diesel
Engine oil:Must be to A.P.I. Classification CJ-4 grade.
TEMPERATURE VISCOSITY
Above 25°C (77°F) SAE30 or SAE10W-30 or 15W-40
0°C to 25°C (32°F to 77°F) SAE10W-30 or 15W-40
Below 0°C (32°F) SAE10W-30
TIRE PRESSURE
Product
Front Wheel Rear Wheel
Tire Size Tire Type Tire Pressure Tire Size Tire Type Tire Pressure
HR800 26.5 x 14.00 - 12 Ultra Chevron 6pr
1.10 bar
(16 psi)
20.00 x 10.00 - 8 Grassmaster 8pr
2.07 bar
(30 psi)
HR800 with Cab 26.5 x 14.00 - 12 Ultra Chevron 6pr
1.24 bar
(18 psi)
20.00 x 10.00 - 8 Grassmaster 8pr
2.21 bar
(32 psi)
Caster Wheels 11 x 4 - 5 Smooth
1.38-1.72 bar
(20-25 psi)
