OPERATION 5
en-56
5.4 STARTING THE ENGINE ____________________________________________________
Start the engine with the operator in the seat, the mow switch (A) in
the OFF position and the parking brake switch (B) in the ON position.
Remove your foot from the traction pedal. Always wear the seat belt.
Set the throttle control (C) to half throttle.
Turn the ignition switch (D) to the START position. Release the key
when the engine starts. Allow 30 seconds between start tries to allow
the starter motor to become cool.
When the engine starts, release the ignition switch (D) and move the
throttle control (C) to the low idle position. Allow the engine to become
warm before you operate the engine at full throttle.
5.5 TO STOP THE ENGINE _____________________________________________________
To stop and park the mower in normal conditions:
1. Turn the mow switch to the OFF position. Drive the mower to a flat and level area to park the mower.
2. Remove your foot from the traction pedal.
3. Lower the front and rear cutting units to the ground. Engage the parking brake.
4. Allow the engine to operate at low idle without load for 4 to 5 minutes.
5. Turn the ignition switch to the OFF position and remove the key before you leave the operator seat.
If an emergency occurs and you must park the mower in the area of operation, follow the guidelines set by the grounds
manager. If the mower is parked on a slope, chock or block the wheels.
NOTICE
Do not hold the ignition switch in the START position for more
than 10 seconds.
NOTICE
When you do not operate the engine at no load before you stop the engine, permanent damage to the turbocharger
can occur. Run the engine at no load and the throttle at 50% for 4 to 5 minutes to allow the turbocharger to become
cool before you stop the engine.
12V
A
B
12V
1
0A
D
C
MODE
