Jacobsen HR800 Service Manual

6 ADJUSTMENTS
en-65
6.6 HEIGHT OF CUT ADJUSTMENT______________________________________________
The cutting height is determined by the position of the blades in relation to the caster wheels. Changes to this height
are made at all points and can be made in any order. Make adjustment selections for each deck from the height of cut
chart for that deck included in this section.
NOTES
• Cutting height must be set the same for all three cutter decks.
• The actual height may vary slightly from the chart value because of tire pressure or turf condition.
6.7 HEIGHT OF CUT ADJUSTMENT (FRONT DECK) ________________________________
1. Raise the deck to mid position.
2. Remove the quick pin (A) from the top of the caster wheel pivot spindle
3. Remove the caster wheel from caster support (B).
4. Select either Position 1 or Position 2 for wheel mounting bracket (C). To
change, remove (4) mounting bolts (D), move to the alternate location
and bolt in place.
5. Place the selected number of spacers (E) below the caster support.
Place the remaining spacers above the caster support.
6. Replace the quick pin.
7. Place pin (F) into the proper hole of bracket for the selected height of
cut and fit quick pin.
A
B
D
C
E
F
G
K
K
X
X
1-2-3S
S
1.0 IN
1.5 IN
2.0 IN
2.5 IN
3.0 IN
3.0 IN
3.5 IN
4.0 IN
4.5 IN
5.0 IN
5.0 IN
5.5 IN
6.0 IN
25 MM A
A
10
28 MM B
B
11
50 MM C
C
12
63 MM D
D
1 3
76 MM E
E
14
76 MM E 2 0
88 MM F
F
21
101 MM G
G
22
114 MM H
H
2 3
127 MM J
J
24
127 MM J 3
1
2
3
0
140 MM K
K
3 1
152 MM L
L
3 2
4339906
