11.8 CUTTER DECK SPECIFICATION _____________________________________________
Product HR800 Front Deck
Deck Width 183 cm (72 inch) Deck (Front)
Construction
Bull nose profile, steel construction. Solid bumper rails, bolted assembly of all impact and
wearing parts.
Blade Length 635 mm (25 inch)
Number of Blades 3
Blade Tip Speed 4942 m/minute (16214 feet/minute)
Height of Cut 25 mm - 152 mm (1 inch - 6 inch) 12.7 mm (1/2 in) increments. Tools-less adjustment.
Height of Cut Adjust-
ment Front
Two castor wheels, with spacers. tires 11 X 4.00 - 5 smooth, pneumatic, taper roller bearings.
Height of Cut Adjust-
ment Rear
Front deck pin and slot. Wing deck chain and Pin
“Anti Scalp” Roll Three anti scalp rollers on the front of deck and three anti scalp rollers on the rear.
Transmission By Hydraulic motor to each cutter blade.
Product HR800 Wing Deck
Deck Width 167 cm (66 inch) Deck (Wing)
Construction
Bull nose profile, steel construction. Solid bumper rails, bolted assembly of all impact and
wearing parts.
Blade Length 584.2 mm (23 inch)
Number of Blades 3
Blade Tip Speed 4955 m/minute (16257 feet/minute)
Height of Cut 25 mm - 152 mm (1 inch - 6 inch) 12.7 mm (1/2 in) increments. Tools-less adjustment.
Height of Cut Adjust-
ment Front
Two castor wheels,. tires 11 X 4.00 - 5 smooth, pneumatic, taper roller bearings.
Height of Cut Adjust-
ment Rear
Two castor wheels, with spacers. tires 11 X 4.00 - 5 smooth, pneumatic, taper roller bearings.
Wing deck chain and Pin
“Anti Scalp” Roll One anti scalp rollers 3 in. on the front of deck and one anti scalp roller 5 x 2-3/4 in. on the rear.
Transmission By Hydraulic motor to each cutter blade.
