37
UMG 511
Fig. connection of two relays
to the digital outputs 4 and 5.
16
K1 K2
24V
AC
External
Auxiliary voltage
UMG511
Digital Outputs 1-5
12
Digital
Output 5
13
Digital
Output 4
14
Digital
Output 3
15
Digital
Output 2
Digital
Output 1
11
~~
16
