87
UMG 511
General
Net weight 1080g
Device dimensions approx. l=144mm, w=144mm, h=75mm
Battery Typ VARTA CR1/2AA, 3 V, Li-Mn
Technical data
Transport and storage
The following details are valid for devices that are transported or stored in the original packaging.
Drop test 1m
Temperature -20°C to +70°C
Environmental conditions in operation
The UMG511is intended for use in a weather-protected, fixed extradata.
The UMG511 must be connected to the protective wire connection! Protection class I according to IEC 60536
(VDE 0106, part 1)
Working temperature range -10°C .. +55°C
Relative humidity 5 to 95 %, (at +25 °C) without condensation
Degree of pollution 2
Operating height 0 .. 2000m above sea level
Installation position user-defined
Ventilation external ventilation is not required.
Foreign particles and water protection
- Front
- Back
IP50 according to EN60529
IP20 according to EN60529
