Jasic EVOLVE 200 - MMA Synergic Materials and Electrode Size

EVOLVE 200 USER MANUAL
20
On the right side, the display will show the thickness of the
work part with selected current.
The 2T/4T button can be used to set VRD ON or VRD OFF.
The electrode synergic settings are similar for other materials.
Stick synergic Materials and Electrode size
Material Electrode size (mm)
RUTIL 2,0-2,5-3,25-4,0
SST 2,0-2,5-3,25-4,0
BASIC 2,5-3,25-4,0
ALMG 2,5-3,25
CELL 2,5-3,25-4,0
