EVOLVE 200 USER MANUAL
24
2.7.3 SETTING TIG PULSE
2.7.3.1 Electrode adjustments
To select the TYPE of TIG MODE, push the MODE button
twice.
Select the TIG TYPE by rotating KNOB1 and confirm by
pushing the KNOB1.
Press the PROG button twice to enter in the tungsten diameter
selection menu. Select the diameter by KNOB1 and confirm by
pushing the KNOB1.
2.7.3.2 2T/4T Setting
Push the 2T/4T button to enter in the 2T/4T menu.
Select the 2T/4T by KNOB1 and confirm by pushing the
KNOB1.
It is possible to select 2 Time, 4 Time, SP (SPOT).
2.7.3.3 SETTING menu
SETTING MENU
Push the SETTING button to enter in the setting menu.
SELECT the sub menu by knob1 and confirm by pushing the
knob1.
- Technical Parameter (See Table 2.2)
- MACHINE INFO: can show the machine SN and more
information.
- RESTORE FACTORY: restore default settings of the working
data in the selected welding section.
