Troubleshooting
D1 red led
D2
green
led Message / issue Solution
Flash at beginning
of opening
OFF
Control panel asks RS3 correct signal
transmitter to start the manoeuvre
---
Flash at beginning
of closing
OFF
Indicates calibration failure of RS3
transmitter in open door status
Reprogram the manoeuvre until no
calibration failure
ON OFF
Indicates that the door is passing
through the inhibition zones. It is only
indicated in the first 25 manoeuvres
OFF ON Indicates very good coverage
OFF Flash Indicates very regular coverage
Align parallel the RS3 transmitter
antenna and REC3 antenna
OFF OFF
Indicates poor coverage or no cov-
erage
Align parallel the RS3 transmitter
antenna and REC3 antenna or
change equipments location
Technical Data
Parameter Value
Incorporated receiver RS3 TGL868
Operating frequencies
Multifrequency system 868 MHz auto-adjustable (Channel 1: 868,700
869,200MHz¸Channel 2: 868,000 -868,600MHz; Channel 3: 869,400
869,650MHz; Channel 4: 869,400 -869,650MHz)
Memory
3 transmitters RBAND3 or 1 trans-
mitter RSENS3
---
Standby / Operating consumption --- 0.3mA / 12mA
Radiated power <1mW
Range (in open field) 50m
Battery life (approx) --- See battery life table
Compatible equipments
RB3 T868, RB3 TGL868 and RB3
TGLA868 or RS3 T868, RS3
TGL868
Incorporated receiver
Watertighness --- IP22
Reaction time (typical) 18 ms (max 48 ms)
Maximum reaction time when inter-
ferences
466ms
Operating temperature -20ºC to +55º
