RadioBand System
Installation
Connection
IN1 Connection SW1:1 SW1:2
JCM Optical safety edge (OSE-S7502B and OSE-S7502) OFF OFF
Standard optical safety edge ON OFF
8k2 resistive safety edge OFF ON
NC contact* ON ON
IN2 Connection SW1:3
NC contact* ON
8k2 resistive safety edge OFF
* In order to comply with the EN 12453:2017 safety standard, NC contact input can not be used
to connect safety devices.
jcmtechnologies
25
