356 IN CASE OF EMERGENCY
Mounting Fuse Cover and Locking Screw
Proceed as follows:
1. Properly secure the fuse cover to the box, slide
completely from top to bottom.
2. Fully depress the screw, using the special screwdriver
supplied, in the rear cargo area.
3. Slowly turn the screw clockwise.
4. Release the screw.
Battery Fuse Cover Location
1 — Fuse Cover Tabs
2 — Fuse Cover
Cavity Maxi Fuse Cartridge Fuse Mini Fuse Description
F01 70 Amp Tan – – Module Body Computer
F02 70 Amp Tan – –
Module Body Computer,
Rear Distribution Units
F03 –
30 Amp Pink with HID
Lamps
20 Amp Blue without
HID Lamps
–
Supply Body Computer,
HID Lamps
