IN CASE OF EMERGENCY 357
F04 – 40 Amp Tan –
Brake Control Electronics
Module
F05 – 40 Amp Tan – PTC Heater
F06 40 Amp Orange – – Starter Relay
F07 40 Amp Orange – –
Rear Distribution Unit For
Trailer Tow Usage
F08 – 30 Amp Pink –
Supply For TCM, AGSM,
Steering Control
F09 – – 7.5 Amp Brown
ECM, TCM, Radiator Fan
Control
F10 – – 20 Amp Yellow Horn
F11 – –
20 Amp Yellow – 1.4L
Gas & Diesel Engines
25 Amp Clear – 2.4 L
Engines/UREA
ECM/PCM/UREA Fuel
Injectors
F14
– – 7.5 Amp Brown Diesel Crankcase Heater
F15 40 Amp Orange – –
Brake Control Module
Pump
F16 – – 10 Amp Red
Engine Control Module
Power, Automatic
Transmission
Cavity Maxi Fuse Cartridge Fuse Mini Fuse Description
6
