F17 – – 10 Amp Red Engine Secondary Loads
F18 – – 20 Amp Yellow
12V Rear Cargo Outlet
Ignition Powered
F19 – – 7.5 Amp Brown
Air Conditioner
Compressor
F20 – – 20 Amp Yellow Cigar Lighter
F21 – – 20 Amp Yellow Fuel Pump
F22 – –
20 Amp Yellow – Gas
Engine
15 Amp Blue – Diesel
Engine
Gas - Ign Coil/Fuel Injector
Diesel- Diesel Components
F23 – – 30 Amp Green Window Heater Grid
F24 – – 15 Amp Blue
Electronic Unit Supply
Automatic Transmission
F30 – –
20 Amp Yellow
(Customer Selectable,
Move From F18)
12V Rear Cargo Outlet
Constant Battery Powered
F81 60 Amp Blue – –
Glow Plug Module, DDCT
SDU Battery Feed
F82 – 40 Amp Green – Diesel Fuel Filter Heater
F83 – 40 Amp Green – HVAC Fan
Cavity Maxi Fuse Cartridge Fuse Mini Fuse Description
