3-MACHINE SIGNALS AND
CONTROLS
______________________________________________________________________________________________
Control and configuration pages:
Hold down ENTER to page to the MAIN MENU
Hold down ESC to exit the MAIN MENU
Press the up and down arrows to scroll the menu (press fast the button)
Press ENTER to select/page to; press ESC to deselect/exit a function
Press ENTER to set the values > an asterisk “*” will appear up the space on the left > change position
of the asterisk “*”using ESC > modify the value by means of arrow + or - > press ENTER to exit (the
asterisk has to be positioned on the last figure on the right and then it disappears)
1- INPUT > page indicating the list of inputs and their state
2- OUTPUT > page indicating the list of outputs and their state
3- ANALOGIC > page indicating the list of analogical inputs-outputs and their state
4- CALIBRATION
o Angle min: __ >enter to set angle min
o Angle max:___> enter to set angle max
o Load min: __ >enter to set load min
o Load max:___> enter to set load max
o Enter to set joy right down
o Enter to set joy right up
o Enter to set joy right zero
o Enter to set joy left down
o Enter to set joy left up
o Enter to set joy left zero
o Joy dead zo
o Enter to set rotation STB1
o Enter to set rotation FRONT
o Enter to set rotation STB4
o Enter to set rotation STB3
o Enter to set rotation REAR
o Enter to set rotation STB2
5- MACHINE PAR.
o Max pression
o Min pression
o Max load
o PWM-M
o PWM-M-T
6- MACHINE OPE.
o n° rope (1,2,3)
o n° tool (
0 > Winch 1 M > Manipulator MV300.3 2 JH > Hydraulic Jib with hook 3 JM >
Mechanical Jib 4H > Hook 5 M2 > manipulator MR800.4 6 JW > Hydraulic Jib with rope)
o RO-S ABCDEFRX
o Imperial Unit: 0 > E.U. / 1 > Imp. Unit
7- BY-PASS
o Crane (when activated by pressing ENTER, the corresponding led will flash and the ring
turn on)
o Truck (when activated by pressing ENTER, the corresponding led will flash and the
ring turn on )
8- TIMER
