Page 42 of 97
3-MACHINE SIGNALS AND
CONTROLS
______________________________________________________________________________________________
o HTM: (hours) total machine - total working hours of the machine
o HDM: (hours of) diesel engine (only diesel engine) working hours - when diesel engine
machine
o HDK: : (hours of) "power pack" working hours - only on Diesel machine equipped by
power pack - 3 Phase or Monophase
o HEB (hours of) electric battery (only on electric +24Vdc machine) working hours - when
24Vdc battery machine
o HEK: (hours of) "power pack" working hours (only on electric +24Vdc machine) - when
24Vdc battery machine equipped by power pack - 3 Phase or Monophase
o MNM: hour counter of maintenance for the whole machine
o MND : hour counter of maintenance for the diesel engine (only for machine equipped by
diesel engine)
o Enter to set reset time 1
o Enter to set reset time 2
MN.D is different to MN.M cause of the engine has a different maintenance schedule (and with
different time)
9- SAVE
CAUTION!!!
Configuration pages 4 and 5 can be paged to only by entering a password supplied under the
manufacturer’s authorization.
After modifying the settings, page to the SAVE page and save by pressing ENTER.
Key alternate functions:
TEMPORARY BY-PASS
: in case of overload, some moves of the crane might be deactivated for
safety purposes. If it is necessary to carry out these moves in order to overcome the emergency
condition, follow the procedure here below:
o Press the two arrows on the switchboard at the same time, the buzzer will stop in 5
seconds, the three-colour LEDs near the ENTER/ESC keys start flashing in order to
indicate that the by-pass is activated. At this point, the operator is allowed 10 seconds to
carry out the necessary moves. This procedure can be repeated three times provided a
one-minute interval is left between one and the next. When the emergency condition is
over, switch the switchboard off and then switch it on again.
FIXED BY-PASS:
it is activated by paging from the main menu to page 7. The by-pass CRANE
activates all the crane moves, the by-pass TRUCK activates all the truck moves. CAUTION!!! USE
THIS PROCEDURE VERY CAREFULLY SINCE IT CUTS OUT ALL THE MACHINE SAFETY
SYSTEMS.
CAUTION!!!
Stop and restart the machine after using the fixed by-pass in order to go back to the basic
settings.
ANTICOLLISION SYSTEM:
lift up the boom to the intended angle, press arrow + ; when the
value is saved, the two LEDs of the ESC key will flash in turn.
Press arrow - to deactivate the system. ( the yellow led turn on)
