Page 79 of 97
11 – ENCLOSURE
______________________________________________________________________________________________
State IN-OUT (Page 1)
DESCRIPTION Higher than 0 > * Equal to 0 > -
HEAD I-HO
0 Front right cross piece
1 Front left cross piece
2 Back right cross piece
3 Back left cross piece
4 Front right stabilizer
5 Front left stabilizer
6 Back right stabilizer
7 Back left stabilizer
8 Engine thermal sensor
9 Manual accelerator/stabilizer lever downward
ARM I-AO
0 Crane in rest position (closed)
1 Crane left side
2 Jib alarm
3 Crane right side
4 Rope in
5 Jib activated
6 Rope out
SLIM I-SO
0 Sb deadman right control
1 Sb deadman left control
2 Sa remote key (on main switchboard)
3 Sa engine start
4 Sa emergency mushroom push button
5 SbSel1 right – three-phase engine off
6 SbSel1 left – three-phase engine on
7 SbSel2 right – aux off
8 SbSel2 left – aux on
9 SbSel3 right – selection of crane on the right
SLIM I-S1
0 SbSel3 left – selection of manipulator on the left
1 SbSel4 right – selection of crane on the right
2 SbSel4 right – selection of manipulator on the right
3 SLIM up key
4 SLIM down key
5 SLIM index key
6 SLIM enter key
RADIO CONTROL I-RO
0 Ra-p1 automatic acceleration
1 Ra-p2 not used
2 Ra-p3 not used
3 Ra-p4 engine stop
4 Ra-p5 engine start
5 Ra-p6 acceleration
6 Ra-p7 not used
